Vulcan (AR-5) Class: Photographs

These photographs were selected to show the original configuration of this class and major subsequent modifications. For most classes many other photographs exist.
For more complete online collections of U. S. Navy ship photographs see in particular the U. S. Naval Historical Center Online Library and the NavSource Photo Archive.

Click on the small photograph to prompt a larger view of the same image.

USS Vulcan (AR-5)

Near the Philadelphia Navy Yard on 21 August 1941 two months after completion.
Note the splinter protection (gun tubs) around the 5"/38 gun mounts.

Photo No. 19-N-25376
Source: U.S. National Archives, RG-19-LCM

USS Vulcan (AR-5)

Near the Norfolk Navy Yard on 10 June 1942 wearing pattern camouflage.
The splinter protection around the 5"/38 gun mounts has been removed.

Photo No. 19-N-30314
Source: U.S. National Archives, RG-19-LCM

USS Ajax (AR-6)

Off San Pedro, California, on 23 November 1943.

Photo No. 19-N-85764
Source: U.S. Naval Historical Center

USS Vulcan (AR-5)

Near the Norfolk Navy Yard on 10 January 1945.

Photo No. 19-N-97729
Source: U.S. National Archives, RG-19-LCM

USS Jason (ARH-1)

Underway during the 1950s while still classified as the Navy's only heavy hull repair ship (ARH).
Her appearance was essentially identical to that of her repair ship (AR) sisters.

Photo No. USN 1106431
Source: U.S. Naval Historical Center

USS Jason (AR-8)

Underway after her 5" guns were removed circa 1974.
Note that the mainmast is now a tall tripod.

Photo No. USN 1106431
Source: U.S. Naval Historical Center

USS Vulcan (AR-5) Near the Philadelphia Navy Yard on 21 August 1941 two months after completion. Note the splinter protection (gun tubs) around the 5"/38 gun mounts. Photo No. 19-N-25376 Source: U.S. National Archives, RG-19-LCM
USS Vulcan (AR-5) Near the Norfolk Navy Yard on 10 June 1942 wearing pattern camouflage. The splinter protection around the 5"/38 gun mounts has been removed. Photo No. 19-N-30314 Source: U.S. National Archives, RG-19-LCM
USS Ajax (AR-6) Off San Pedro, California, on 23 November 1943. Photo No. 19-N-85764 Source: U.S. Naval Historical Center
USS Vulcan (AR-5) Near the Norfolk Navy Yard on 10 January 1945. Photo No. 19-N-97729 Source: U.S. National Archives, RG-19-LCM
USS Jason (ARH-1) Underway during the 1950s while still classified as the Navy's only heavy hull repair ship (ARH). Her appearance was essentially identical to that of her repair ship (AR) sisters. Photo No. USN 1106431 Source: U.S. Naval Historical Center
USS Jason (AR-8) Underway after her 5" guns were removed circa 1974. Note that the mainmast is now a tall tripod. Photo No. USN 1106431 Source: U.S. Naval Historical Center
