Coronis (ARL-10) Class: Photographs

These photographs were selected to show the original configuration of this class and major subsequent modifications. For most classes many other photographs exist.
For more complete online collections of U. S. Navy ship photographs see in particular the U. S. Naval Historical Center Online Library and the NavSource Photo Archive.

Click on the small photograph to prompt a larger view of the same image.

USS Patroclus (ARL-19)

Near Baltimore, Md., on 18 April 1945 after completion of conversion.
The bow doors on this class were fully operational.

Photo No. 19-N-82466
Source: U.S. National Archives, RG-19-LCM

USS Patroclus (ARL-19)

Underway "with a bone in her teeth" in Hampton Roads, Va., on 2 May 1945.

Photo No. Unknown
Source: U.S. National Archives, RG-19-LCM

USS Stentor (ARL-19)

In Mobile Bay, Ala., on 3 May 1945 after completion of conversion.
The ships of this class had no 3"/50 aft, instead the after 40mm quadruple mount was on a high platform over the stern.

Photo No. 19-N-82887
Source: U.S. National Archives, RG-19-LCM

USS Proserpine (ARL-21)

In the port of Jacksonville, Fla., on 10 June 1945 after completion of conversion.
Note the two tall kingposts forward, considerably closer together than on the Achelous (ARL-1) class.

Photo No. 19-N-86800
Source: U.S. National Archives, RG-19-LCM

USS Krishna (ARL-38)

Probably photographed during the 1960s. The mainmast is now a tripod. This was the only ARL to serve continuously from the 1940s into the 1970s without spending time in reserve.

Photo No. Unknown
Source: U.S. Naval Historical Center

USS Askari (ARL-30)

Operating in South Vietnam on 27 September 1967 as part of River Assault Flotilla ONE.
She has used her "A" frame hoist to lift a 56-foot Armored Troop Carrier (ATC) onto a pontoon for maintenance. Other riverine craft, including a monitor, await their turn. The full load displacement of an ATC was 69.2 tons and its hoisting weight was 55.8 tons, suggesting that Askari and its sisters had the improved 60-ton capacity "A" frame hoist.

Photo No. 19-N-85764
Source: U.S. National Archives, RG-19-LCM

USS Satyr (ARL-23)

Anchored in the Mekong River, probably on 16 February 1971.
The ship was providing support and repairs to river assault craft of the Vietnamese Navy. The 56-foot Armored Troop Carrier (ATC) alongside is the South Vietnamese HQ.1223. Satyr was transferred to South Vietnam later in 1971.

Photo No. 19-N-87305
Source: U.S. National Archives, RG-19-LCM
